MODEL 970SL LED SEARCHLIGHT

Features:
  • 10pcs LED with reflector optics

  • Peak Beam Intensity: 350,000 Candelas

  • Spot with 8 Degree Beam

  • 135º tilt X 360 º continuous rotation

  • Weatherproof  Plastic Housing with cover

  • Durable Integrated Motor

  • Black / White Color

  • DC 12V & DC 24V Both

  • Wired & Wireless remote control

  • Automatically return to home position when searchlight is switched off.

  • FCC , EN60945 Certificated

Model 970SL Specifications:

  • Housing :

Acrylonitrile Styrene Acrylate (ASA) plastic resin

135° Tilt x 360° Unlimited Continuous Rotation

Weather Resistance : ANTI-UV / ANTI-SALT / IP66

Operating Temperature Range: -30℃ ~ +70℃

Color : White / Black

          Size : 242(L)x215(W)X201(H)mm

          Mount type : Permanent (Portable magnetic shoe optional )

          Weight : 2.5Kgs (5.4lbs)

970SL 970SH 4 Sides.jpg
  • Lamp :

LED  x 10PCS

Watts: 50W

Current consumption : 13.8V  4.0A (MAX) / 28.0V   2.0A (MAX)

Color Temperature: 5000K

Beam Pattern : Spot with 8 Degree Beam

Luminous intensity: 350000 Candle Power

Beam distance: 1183M

IP 68 Compliant

Aluminum Housing as Heat Sink

Reflector optics



970SL Searchlight Black Color
970SL Searchlight White Color
970SL Searchlight White Color
970SL Searchlight White Color
970SL 970SH wiring map.jpg
